Thermo Scientific™

Evolution™ 260 Bio UV-Visible Spectrophotometer

Name: Evolution™ 260 Bio UV-Visible Spectrophotometer
SKU: 912A0888

Catalog number: 912A0888

Related applications: Spectroscopy, Elemental & Isotope Analysis

Technical SupportCustomer Service

Evolution™ 260 Bio UV-Visible Spectrophotometer

Thermo Scientific™

Evolution™ 260 Bio UV-Visible Spectrophotometer

Catalog number: 912A0888

Related applications: Spectroscopy, Elemental & Isotope Analysis

Technical SupportCustomer Service

New sales of this model have been discontinued. Please see the newest models: the Evolution Pro Spectrophotometers.

Catalog Number

912A0888

Unit Size

Each

Description

Evolution 260 Bio Spectrophotometer plus Tablet Control Module - International

Price (USD)

Full specifications

Baseline Flatness	±0.0010 A, 200 to 800 nm, 1.0 nm SBW, smoothing
Certifications/Compliance	ISO 9001:2008
Description	Evolution 260 Bio Spectrophotometer plus Tablet Control Module - International
Detector Type	Dual Silicon Photodiodes
Display	Touchscreen LCD panel, 800 x 480 pixels, 17.8 cm (7 in. diagonal)
Dimensions (L x W x H)	62.2 x 48.6 x 27.9 cm (24 x 19 x 11 in.)
Spectral Bandwidth	Variable: 1.0 nm, 2.0 nm
Wavelength Range	190 to 1100 nm
Drift	<0.0005 A/hr., 500 nm, 1.0 nm SBW, 1 hr. warmup
Electrical Requirements	100/240 V, 50/60 Hz selected automatically, 150 W maximum
For Use With (Application)	Spectroscopy Elemental Isotope Analysis
Keypad	Sealed membrane
Lamp Life	7 years typical
Noise	0A: <0.00015A 1A: <0.00025A 2A: <0.00080A 260nm, 1.0nm SBW, RMS
Optical Design	Double Beam with sample and reference cuvette positions; Application Focused Beam Geometry; Czerny-Turner Monochromator
Pharmacopoeia Compliance Testing	(Guaranteed Performance Specifications) Resolution (toluene in Hexane): ≥1.8A Photometric Accuracy (60mg/L K₂Cr₂O₇): ±0.010A Stray Light: ≤1%T at 198nm: KCI; ≤0.05%AT at 220nm: Nal, KI Wavelength Accuracy: ±0.5nm 541.9, 546.1nm Hg emission lines, ±0.8nm full range Wavelength Repeatability: ≤0.05nm, repetitive scanning of 546.1nm Hg emission line
Photometric Display	-0.3 - 4.0A
Photometric Range	>3.5A
Photometric Repeatability	±0.0002 A
Processor	Microsoft Windows™ XP embedded INSIGHT 2 Software is also compatible with Windows 7 and Windows 8.1 Professional Editions and can be installed on a computer attached to the instrument
Scan Ordinate Modes	Absorbance, % Transmittance, % Reflectance, Kubelka-Munk, log (1/R), log (Abs), Abs*Factor, Intensity
Scan Speed	<1 to 6000 nm/min. (Variable)
Warranty	3 Years
Wavelength Accuracy	±0.5 nm (541.9, 546.1 nm mercury lines), ±0.8 nm (full range 190 to 1100 nm)
Wavelength Data Interval	10, 5, 2, 1.0, 0.5, 0.2, 0.1 nm
Weight (Metric)	14.4 kg
Unit Size	Each

Catalog Number

840-211000

Unit Size

Each

Description

Evolution 260 Bio UV-Vis Spectrophotometer, Computer Control, includes Euro/US/UK power cords

Price (USD)

Full specifications

Baseline Flatness	±0.0010 A, 200 to 800 nm, 1.0 nm SBW, smoothing
Certifications/Compliance	ISO 9001:2008
Description	Evolution 260 Bio UV-Vis Spectrophotometer, Computer Control, includes Euro/US/UK power cords
Detector Type	Dual Silicon Photodiodes
Dimensions (L x W x H)	62.2 x 48.6 x 27.9 cm (24 x 19 x 11 in.)
Product Line	Evolution 260 Bio
Spectral Bandwidth	Variable: 1.0 nm, 2.0 nm
Type	Computer Control UV-Vis Spectrophotometer
Wavelength Range	190 to 1100 nm
Drift	<0.0005 A/hr., 500 nm, 1.0 nm SBW, 1 hr. warmup
Electrical Requirements	100/240 V, 50/60 Hz selected automatically, 150 W maximum
Includes	EU/US/UK power cords
Lamp Life	7 years typical
Noise	0A: <0.00015A 1A: <0.00025A 2A: <0.00080A 260nm, 1.0nm SBW, RMS
Optical Design	AFBG microcell optimized, AFBG fiber optic optimized, AFBG materials optimized
Pharmacopoeia Compliance Testing	(Guaranteed Performance Specifications) Resolution (toluene in Hexane): ≥1.8A Photometric Accuracy (60mg/L K₂Cr₂O₇): ±0.010A Stray Light: ≤1%T at 198nm: KCI; ≤0.05%AT at 220nm: Nal, KI Wavelength Accuracy: ±0.5nm 541.9, 546.1nm Hg emission lines, ±0.8nm full range Wavelength Repeatability: ≤0.05nm, repetitive scanning of 546.1nm Hg emission line
Photometric Display	-0.3 - 4.0A
Photometric Range	>3.5A
Photometric Repeatability	±0.0002 A
Processor	Microsoft Windows 7, Windows 8
Scan Ordinate Modes	Absorbance, % Transmittance, % Reflectance, Kubelka-Munk, log (1/R), log (Abs), Abs*Factor, Intensity
Scan Speed	<1 to 6000 nm/min. (Variable)
Warranty	3 Years
Wavelength Accuracy	±0.5 nm (541.9 nm mercury lines), ±0.8 nm (full range 190 to 1100 nm)
Wavelength Data Interval	10, 5, 2, 1.0, 0.5, 0.2, 0.1 nm
Weight (English)	32 lb.
Weight (Metric)	14.4 kg
Unit Size	Each

Catalog Number

912A0885

Unit Size

Each

Description

Evolution 260 Bio Spectrophotometer plus Tablet Control Module - US CAN JP

Price (USD)

Full specifications

Baseline Flatness	±0.0010 A, 200 to 800 nm, 1.0 nm SBW, smoothing
Certifications/Compliance	ISO 9001:2008
Description	Evolution 260 Bio Spectrophotometer plus Tablet Control Module - US CAN JP
Detector Type	Dual Silicon Photodiodes
Display	Touchscreen LCD panel, 800 x 480 pixels, 17.8 cm (7 in. diagonal)
Dimensions (L x W x H)	62.2 x 48.6 x 27.9 cm (24 x 19 x 11 in.)
Product Line	Evolution 260 Bio
Spectral Bandwidth	Variable: 1.0 nm, 2.0 nm
Type	Spectrophotometer plus Tablet Control Module - US, CAN, JP
Wavelength Range	190 to 1100 nm
Drift	<0.0005 A/hr., 500 nm, 1.0 nm SBW, 1 hr. warmup
Electrical Requirements	100/240 V, 50/60 Hz selected automatically, 150 W maximum
Keypad	Sealed membrane
Lamp Life	7 years typical
Noise	0A: <0.00015A 1A: <0.00025A 2A: <0.00080A 260nm, 1.0nm SBW, RMS
Optical Design	AFBG microcell optimized, AFBG fiber optic optimized, AFBG materials optimized
Pharmacopoeia Compliance Testing	(Guaranteed Performance Specifications) Resolution (toluene in Hexane): ≥1.8A Photometric Accuracy (60mg/L K₂Cr₂O₇): ±0.010A Stray Light: ≤1%T at 198nm: KCI; ≤0.05%AT at 220nm: Nal, KI Wavelength Accuracy: ±0.5nm 541.9, 546.1nm Hg emission lines, ±0.8nm full range Wavelength Repeatability: ≤0.05nm, repetitive scanning of 546.1nm Hg emission line
Photometric Display	-0.3 - 4.0A
Photometric Range	>3.5A
Photometric Repeatability	±0.0002 A
Processor	Microsoft Windows™ XP embedded INSIGHT 2 Software is also compatible with Windows 7 and Windows 8.1 Professional Editions and can be installed on a computer attached to the instrument
Scan Ordinate Modes	Absorbance, % Transmittance, % Reflectance, Kubelka-Munk, log (1/R), log (Abs), Abs*Factor, Intensity
Scan Speed	<1 to 6000 nm/min. (Variable)
Warranty	3 Years
Wavelength Accuracy	±0.5 nm (541.9, 546.1 nm mercury lines), ±0.8 nm (full range 190 to 1100 nm)
Wavelength Data Interval	10, 5, 2, 1.0, 0.5, 0.2, 0.1 nm
Weight (Metric)	14.4 kg
Unit Size	Each

Catalog Number

912A0885-1Y

Unit Size

Each

Description

Evolution 260 Bio UV-Vis Spectrophotometer with Tablet & 1 year Extended Warranty

Price (USD)

Full specifications

Description	Evolution 260 Bio UV-Vis Spectrophotometer with Tablet & 1 year Extended Warranty
Unit Size	Each

Catalog Number

912A0885-2Y

Unit Size

Each

Description

Evolution 260 Bio UV-Vis Spectrophotometer with Tablet & 2 year Extended Warranty

Price (USD)

Full specifications

Description	Evolution 260 Bio UV-Vis Spectrophotometer with Tablet & 2 year Extended Warranty
Unit Size	Each

Catalog Number

912A0885-3Y

Unit Size

Each

Description

Evolution 260 Bio UV-Vis Spectrophotometer with Tablet & 3 year Extended Warranty

Price (USD)

Full specifications

Description	Evolution 260 Bio UV-Vis Spectrophotometer with Tablet & 3 year Extended Warranty
Unit Size	Each

Catalog Number

840-211000-1Y

Unit Size

Each

Description

Evolution 260 Bio UV-Vis Spectrophotometer with 1 year Extended Warranty

Price (USD)

Full specifications

Description	Evolution 260 Bio UV-Vis Spectrophotometer with 1 year Extended Warranty
Product Line	Evolution 260 Bio
Type	UV-Vis Spectrophotometer
Warranty	1 Year Extended Warranty
Unit Size	Each

Catalog Number

840-211000-2Y

Unit Size

Each

Description

Evolution 260 Bio UV-Vis Spectrophotometer with 2 year Extended Warranty

Price (USD)

Full specifications

Description	Evolution 260 Bio UV-Vis Spectrophotometer with 2 year Extended Warranty
Product Line	Evolution 260 Bio
Type	UV-Vis Spectrophotometer
Warranty	2 Year Extended Warranty
Unit Size	Each

Catalog Number

840-211000-3Y

Unit Size

Each

Description

Evolution 260 Bio UV-Vis Spectrophotometer with 3 year Extended Warranty

Price (USD)

Full specifications

Description	Evolution 260 Bio UV-Vis Spectrophotometer with 3 year Extended Warranty
Product Line	Evolution 260 Bio
Type	UV-Vis Spectrophotometer
Warranty	3 Year Extended Warranty
Unit Size	Each

Showing 9 of 9

Catalog Number Specifications Unit Size Description Price (USD)

912A0888

Full specifications

Each

Evolution 260 Bio Spectrophotometer plus Tablet Control Module - International

Baseline Flatness	±0.0010 A, 200 to 800 nm, 1.0 nm SBW, smoothing
Certifications/Compliance	ISO 9001:2008
Description	Evolution 260 Bio Spectrophotometer plus Tablet Control Module - International
Detector Type	Dual Silicon Photodiodes
Display	Touchscreen LCD panel, 800 x 480 pixels, 17.8 cm (7 in. diagonal)
Dimensions (L x W x H)	62.2 x 48.6 x 27.9 cm (24 x 19 x 11 in.)
Spectral Bandwidth	Variable: 1.0 nm, 2.0 nm
Wavelength Range	190 to 1100 nm
Drift	<0.0005 A/hr., 500 nm, 1.0 nm SBW, 1 hr. warmup
Electrical Requirements	100/240 V, 50/60 Hz selected automatically, 150 W maximum
For Use With (Application)	Spectroscopy Elemental Isotope Analysis
Keypad	Sealed membrane
Lamp Life	7 years typical
Noise	0A: <0.00015A 1A: <0.00025A 2A: <0.00080A 260nm, 1.0nm SBW, RMS
Optical Design	Double Beam with sample and reference cuvette positions; Application Focused Beam Geometry; Czerny-Turner Monochromator
Pharmacopoeia Compliance Testing	(Guaranteed Performance Specifications) Resolution (toluene in Hexane): ≥1.8A Photometric Accuracy (60mg/L K₂Cr₂O₇): ±0.010A Stray Light: ≤1%T at 198nm: KCI; ≤0.05%AT at 220nm: Nal, KI Wavelength Accuracy: ±0.5nm 541.9, 546.1nm Hg emission lines, ±0.8nm full range Wavelength Repeatability: ≤0.05nm, repetitive scanning of 546.1nm Hg emission line
Photometric Display	-0.3 - 4.0A
Photometric Range	>3.5A
Photometric Repeatability	±0.0002 A
Processor	Microsoft Windows™ XP embedded INSIGHT 2 Software is also compatible with Windows 7 and Windows 8.1 Professional Editions and can be installed on a computer attached to the instrument
Scan Ordinate Modes	Absorbance, % Transmittance, % Reflectance, Kubelka-Munk, log (1/R), log (Abs), Abs*Factor, Intensity
Scan Speed	<1 to 6000 nm/min. (Variable)
Warranty	3 Years
Wavelength Accuracy	±0.5 nm (541.9, 546.1 nm mercury lines), ±0.8 nm (full range 190 to 1100 nm)
Wavelength Data Interval	10, 5, 2, 1.0, 0.5, 0.2, 0.1 nm
Weight (Metric)	14.4 kg
Unit Size	Each

840-211000

Full specifications

Each

Evolution 260 Bio UV-Vis Spectrophotometer, Computer Control, includes Euro/US/UK power cords

Baseline Flatness	±0.0010 A, 200 to 800 nm, 1.0 nm SBW, smoothing
Certifications/Compliance	ISO 9001:2008
Description	Evolution 260 Bio UV-Vis Spectrophotometer, Computer Control, includes Euro/US/UK power cords
Detector Type	Dual Silicon Photodiodes
Dimensions (L x W x H)	62.2 x 48.6 x 27.9 cm (24 x 19 x 11 in.)
Product Line	Evolution 260 Bio
Spectral Bandwidth	Variable: 1.0 nm, 2.0 nm
Type	Computer Control UV-Vis Spectrophotometer
Wavelength Range	190 to 1100 nm
Drift	<0.0005 A/hr., 500 nm, 1.0 nm SBW, 1 hr. warmup
Electrical Requirements	100/240 V, 50/60 Hz selected automatically, 150 W maximum
Includes	EU/US/UK power cords
Lamp Life	7 years typical
Noise	0A: <0.00015A 1A: <0.00025A 2A: <0.00080A 260nm, 1.0nm SBW, RMS
Optical Design	AFBG microcell optimized, AFBG fiber optic optimized, AFBG materials optimized
Pharmacopoeia Compliance Testing	(Guaranteed Performance Specifications) Resolution (toluene in Hexane): ≥1.8A Photometric Accuracy (60mg/L K₂Cr₂O₇): ±0.010A Stray Light: ≤1%T at 198nm: KCI; ≤0.05%AT at 220nm: Nal, KI Wavelength Accuracy: ±0.5nm 541.9, 546.1nm Hg emission lines, ±0.8nm full range Wavelength Repeatability: ≤0.05nm, repetitive scanning of 546.1nm Hg emission line
Photometric Display	-0.3 - 4.0A
Photometric Range	>3.5A
Photometric Repeatability	±0.0002 A
Processor	Microsoft Windows 7, Windows 8
Scan Ordinate Modes	Absorbance, % Transmittance, % Reflectance, Kubelka-Munk, log (1/R), log (Abs), Abs*Factor, Intensity
Scan Speed	<1 to 6000 nm/min. (Variable)
Warranty	3 Years
Wavelength Accuracy	±0.5 nm (541.9 nm mercury lines), ±0.8 nm (full range 190 to 1100 nm)
Wavelength Data Interval	10, 5, 2, 1.0, 0.5, 0.2, 0.1 nm
Weight (English)	32 lb.
Weight (Metric)	14.4 kg
Unit Size	Each

912A0885

Full specifications

Each

Evolution 260 Bio Spectrophotometer plus Tablet Control Module - US CAN JP

Baseline Flatness	±0.0010 A, 200 to 800 nm, 1.0 nm SBW, smoothing
Certifications/Compliance	ISO 9001:2008
Description	Evolution 260 Bio Spectrophotometer plus Tablet Control Module - US CAN JP
Detector Type	Dual Silicon Photodiodes
Display	Touchscreen LCD panel, 800 x 480 pixels, 17.8 cm (7 in. diagonal)
Dimensions (L x W x H)	62.2 x 48.6 x 27.9 cm (24 x 19 x 11 in.)
Product Line	Evolution 260 Bio
Spectral Bandwidth	Variable: 1.0 nm, 2.0 nm
Type	Spectrophotometer plus Tablet Control Module - US, CAN, JP
Wavelength Range	190 to 1100 nm
Drift	<0.0005 A/hr., 500 nm, 1.0 nm SBW, 1 hr. warmup
Electrical Requirements	100/240 V, 50/60 Hz selected automatically, 150 W maximum
Keypad	Sealed membrane
Lamp Life	7 years typical
Noise	0A: <0.00015A 1A: <0.00025A 2A: <0.00080A 260nm, 1.0nm SBW, RMS
Optical Design	AFBG microcell optimized, AFBG fiber optic optimized, AFBG materials optimized
Pharmacopoeia Compliance Testing	(Guaranteed Performance Specifications) Resolution (toluene in Hexane): ≥1.8A Photometric Accuracy (60mg/L K₂Cr₂O₇): ±0.010A Stray Light: ≤1%T at 198nm: KCI; ≤0.05%AT at 220nm: Nal, KI Wavelength Accuracy: ±0.5nm 541.9, 546.1nm Hg emission lines, ±0.8nm full range Wavelength Repeatability: ≤0.05nm, repetitive scanning of 546.1nm Hg emission line
Photometric Display	-0.3 - 4.0A
Photometric Range	>3.5A
Photometric Repeatability	±0.0002 A
Processor	Microsoft Windows™ XP embedded INSIGHT 2 Software is also compatible with Windows 7 and Windows 8.1 Professional Editions and can be installed on a computer attached to the instrument
Scan Ordinate Modes	Absorbance, % Transmittance, % Reflectance, Kubelka-Munk, log (1/R), log (Abs), Abs*Factor, Intensity
Scan Speed	<1 to 6000 nm/min. (Variable)
Warranty	3 Years
Wavelength Accuracy	±0.5 nm (541.9, 546.1 nm mercury lines), ±0.8 nm (full range 190 to 1100 nm)
Wavelength Data Interval	10, 5, 2, 1.0, 0.5, 0.2, 0.1 nm
Weight (Metric)	14.4 kg
Unit Size	Each

912A0885-1Y

Full specifications

Each

Evolution 260 Bio UV-Vis Spectrophotometer with Tablet & 1 year Extended Warranty

Description	Evolution 260 Bio UV-Vis Spectrophotometer with Tablet & 1 year Extended Warranty
Unit Size	Each

912A0885-2Y

Full specifications

Each

Evolution 260 Bio UV-Vis Spectrophotometer with Tablet & 2 year Extended Warranty

Description	Evolution 260 Bio UV-Vis Spectrophotometer with Tablet & 2 year Extended Warranty
Unit Size	Each

912A0885-3Y

Full specifications

Each

Evolution 260 Bio UV-Vis Spectrophotometer with Tablet & 3 year Extended Warranty

Description	Evolution 260 Bio UV-Vis Spectrophotometer with Tablet & 3 year Extended Warranty
Unit Size	Each

840-211000-1Y

Full specifications

Each

Evolution 260 Bio UV-Vis Spectrophotometer with 1 year Extended Warranty

Description	Evolution 260 Bio UV-Vis Spectrophotometer with 1 year Extended Warranty
Product Line	Evolution 260 Bio
Type	UV-Vis Spectrophotometer
Warranty	1 Year Extended Warranty
Unit Size	Each

840-211000-2Y

Full specifications

Each

Evolution 260 Bio UV-Vis Spectrophotometer with 2 year Extended Warranty

Description	Evolution 260 Bio UV-Vis Spectrophotometer with 2 year Extended Warranty
Product Line	Evolution 260 Bio
Type	UV-Vis Spectrophotometer
Warranty	2 Year Extended Warranty
Unit Size	Each

840-211000-3Y

Full specifications

Each

Evolution 260 Bio UV-Vis Spectrophotometer with 3 year Extended Warranty

Description	Evolution 260 Bio UV-Vis Spectrophotometer with 3 year Extended Warranty
Product Line	Evolution 260 Bio
Type	UV-Vis Spectrophotometer
Warranty	3 Year Extended Warranty
Unit Size	Each

Showing 9 of 9

New sales of this model have been discontinued. Please see the newest models: the Evolution Pro Spectrophotometers.
