Process Analytical Technology

Gain efficiencies through gas analysis

The FDA’s Process Analytical Technology (PAT) initiative promotes improved process understanding by defining Critical Process Parameters (CPP) and monitoring these CPPs, either in-line or on-line. Processes can become more efficient, with reduced over-processing and greater product consistency. Gain productivity by instituting a PAT program that is simple, data rich, and low-risk.

For more information, check out our Process Mass Spectrometer Comparison Guide.

Join our community

Featured PAT categories and resources

Fermentation
Track fermentation processes in real time with fast, precise gas analysis

Analysis of respiratory gases is an ideal way of characterizing a fermentation process. It’s non-invasive and provides invaluable information on the physiological state of the culture, including growth kinetics and substrate consumption. It also helps determine the optimum point to halt the process for maximum yield. Many fermentations are characterized by small changes in oxygen and carbon dioxide concentrations. The speed of MS makes it ideal for the fermentation application but speed must not be at the expense of precision. It is equally important that precise data is acquired; otherwise, small changes in concentration will be lost.

Over 30 years of industrial experience have shown that magnetic sector analyzers offer the best performance for fermentation off-gas analysis. Key advantages include improved precision, accuracy, long intervals between calibration, and resistance to contamination. Typically, analytical precision is between 2 and 10 times better than a quadrupole mass spectrometer.

Featured product
Prima BT Bench Top Mass Spectrometer

Prima BT is a highly reliable, precise and flexible gas analyzer specifically designed for process development laboratories. Features include:

  • Scanning magnetic sector technology for fast, flexible, precise multi-component analysis. Concentrations of respiratory gases, inerts and volatiles can be measured in seconds with high levels of precision.
  • 16-port Rapid Multistream Sampler (RMS) for fast, reliable monitoring of multiple fermenters and bioreactors.
  • 21 CFR Part 11 compliant GasWorks software
Prima PRO Process Mass Spectrometer

Prima PRO is currently the world’s leading process mass spectrometer, designed to operate reliably in harsh production environments and backed up with an industry-best three year warranty. Features include:

  • Scanning magnetic sector technology for fast, flexible, precise multi-component analysis. Concentrations of respiratory gases, inerts and volatiles can be measured in seconds with high levels of precision.
  • 32- or 64-port Rapid Multistream Sampler (RMS) for fast, reliable monitoring of multiple fermenters and bioreactors.
  • 21 CFR Part 11 compliant GasWorks software
  • Built-in air conditioner means Prima PRO can operate reliably over a wide ambient temperature range.
Product Drying
Use magnetic sector mass spectrometry to control the solvent drying process with fast, precise, quantitative data

A key stage in many pharmaceutical processes is the complete or partial removal of a solvent or solvents from a product or intermediate. This solvent drying process can occur in a variety of process vessels, including vacuum dryers, tray dryers and rotary dryers.

In the past, the success of the solvent drying process was simply measured at the end by taking a sample for laboratory analysis and the amount of residual solvent was defined by the Loss on Drying (LOD). If the sample failed the LOD test for one or more of the solvents then the drying process had to be restarted. If the drying took place under vacuum this provided additional complications in terms of both sampling the active pharmaceutical ingredient (API) and re-starting the dryer.

Mass spectrometers have been used to monitor solvent levels in the headspace above the API during drying processes but they have typically only produced qualitative or semi-quantitative data. If the MS is to be used as part of a PAT solvent drying process control project, it must produce accurate, reliable quantitative data, even for multi-dryer, multi-solvent systems.

Featured products
Prima PRO Process Mass Spectrometer

Prima PRO VP can monitor up to 10 dryers, with a unique inlet that can switch between dryers at widely differing pressures and concentrations, and still provide reliable, stable solvent concentration data. Features include:

  • Magnetic sector MS, providing stable fragmentation patterns and resistance to contamination
  • 10-port Variable Pressure sampling inlet, able to handle process pressures between 1000 mBar and 0.3 mBar
  • Samples from headspace above the product, measuring the bulk API in the dryer and avoiding problems with grab samples caused by lack of homogeneity.
  • Easy, simple calibration with either gases or liquids ensures accurate quantitative data
  • 21 CFR Part 11 compliant GasWorks software
Thermo Scientific Gas Analysis Mass Spectrometers

Thermo Scientific Gas Analysis Mass Spectrometers have been used successfully for over 30 years on bacterial and microbial processes. More recently, there has been increasing interest in mammalian cell culture because they offer the prospect of radical advances in vaccines, monoclonal antibodies and gene therapy. Although the requirements of mammalian cell fermentation processes provide challenges to the off-gas analyzer, our mass spectrometers have already proved invaluable in improving understanding and increasing yields of mammalian cell cultures.

In mammalian cell fermentations, the feed gas composition is a frequently changing mixture of several compounds. The feed gas concentration also ranges vary dramatically. The implementation of real-time, off-gas Mass Spectrometry in mammalian cell culture can help identify process deviations during bioreactor runs and evaluate batch to batch variation, within predefined specifications, for robust manufacturing.

Prima BT Bench Top Mass Spectrometer

Prima BT is a highly reliable, precise and flexible gas analyzer specifically designed for process development laboratories. Features include:

  • Scanning magnetic sector technology for fast, flexible, precise multi-component analysis. Concentrations of respiratory gases, inerts and volatiles can be measured in seconds with high levels of precision.
  • Configured with 15 sample and 6 calibration ports for fast, reliable monitoring of multiple fermenters and bioreactors using 16-port Rapid Multistream Sampler (RMS).
  • 21 CFR Part 11 compliant GasWorks Process MS Software.
Prima PRO Process Mass Spectrometer

Prima PRO is currently the world’s leading process mass spectrometer, designed to operate reliably in harsh production environments and backed up with an industry-best three year warranty. Features include:

  • Scanning magnetic sector technology for fast, flexible, precise multi-component analysis. Concentrations of respiratory gases, inerts and volatiles can be measured in seconds with high levels of precision.
  • 32- or 64-port Rapid Multistream Sampler (RMS) for fast, reliable monitoring of multiple fermenters and bioreactors.
  • Avoid compromising sterility with non-invasive sampling.
  • 21 CFR Part 11 compliant GasWorks Process MS Software.

Thermo Scientific GasWorks Process MS software provides the unique and powerful interface for the Prima PRO, Prima BT, Sentinel PRO and APIX δQ Mass Spectrometers. The software has been designed to ensure that the process analyzer is simple to configure, operate and maintain without any prior mass spectrometer experience.

The suite includes a wide range of functions and features. Whether the requirement is for a simple alarm indication in the event of a manufacturing process failure, or for complex data presentation for process understanding and control, Gasworks Software is well equipped to offer an effective solution.

  • Supports stand-alone analyzer operation.
  • Sets no limits to the number of sample streams or analytical methods.
  • Includes rigorous mathematical equations to deconvolute complex mixtures.
  • Multi-layered security with expiring passwords and audit trail.
  • Supports the integration of third-party analytical data.
Fermentation
Track fermentation processes in real time with fast, precise gas analysis

Analysis of respiratory gases is an ideal way of characterizing a fermentation process. It’s non-invasive and provides invaluable information on the physiological state of the culture, including growth kinetics and substrate consumption. It also helps determine the optimum point to halt the process for maximum yield. Many fermentations are characterized by small changes in oxygen and carbon dioxide concentrations. The speed of MS makes it ideal for the fermentation application but speed must not be at the expense of precision. It is equally important that precise data is acquired; otherwise, small changes in concentration will be lost.

Over 30 years of industrial experience have shown that magnetic sector analyzers offer the best performance for fermentation off-gas analysis. Key advantages include improved precision, accuracy, long intervals between calibration, and resistance to contamination. Typically, analytical precision is between 2 and 10 times better than a quadrupole mass spectrometer.

Featured product
Prima BT Bench Top Mass Spectrometer

Prima BT is a highly reliable, precise and flexible gas analyzer specifically designed for process development laboratories. Features include:

  • Scanning magnetic sector technology for fast, flexible, precise multi-component analysis. Concentrations of respiratory gases, inerts and volatiles can be measured in seconds with high levels of precision.
  • 16-port Rapid Multistream Sampler (RMS) for fast, reliable monitoring of multiple fermenters and bioreactors.
  • 21 CFR Part 11 compliant GasWorks software
Prima PRO Process Mass Spectrometer

Prima PRO is currently the world’s leading process mass spectrometer, designed to operate reliably in harsh production environments and backed up with an industry-best three year warranty. Features include:

  • Scanning magnetic sector technology for fast, flexible, precise multi-component analysis. Concentrations of respiratory gases, inerts and volatiles can be measured in seconds with high levels of precision.
  • 32- or 64-port Rapid Multistream Sampler (RMS) for fast, reliable monitoring of multiple fermenters and bioreactors.
  • 21 CFR Part 11 compliant GasWorks software
  • Built-in air conditioner means Prima PRO can operate reliably over a wide ambient temperature range.
Product Drying
Use magnetic sector mass spectrometry to control the solvent drying process with fast, precise, quantitative data

A key stage in many pharmaceutical processes is the complete or partial removal of a solvent or solvents from a product or intermediate. This solvent drying process can occur in a variety of process vessels, including vacuum dryers, tray dryers and rotary dryers.

In the past, the success of the solvent drying process was simply measured at the end by taking a sample for laboratory analysis and the amount of residual solvent was defined by the Loss on Drying (LOD). If the sample failed the LOD test for one or more of the solvents then the drying process had to be restarted. If the drying took place under vacuum this provided additional complications in terms of both sampling the active pharmaceutical ingredient (API) and re-starting the dryer.

Mass spectrometers have been used to monitor solvent levels in the headspace above the API during drying processes but they have typically only produced qualitative or semi-quantitative data. If the MS is to be used as part of a PAT solvent drying process control project, it must produce accurate, reliable quantitative data, even for multi-dryer, multi-solvent systems.

Featured products
Prima PRO Process Mass Spectrometer

Prima PRO VP can monitor up to 10 dryers, with a unique inlet that can switch between dryers at widely differing pressures and concentrations, and still provide reliable, stable solvent concentration data. Features include:

  • Magnetic sector MS, providing stable fragmentation patterns and resistance to contamination
  • 10-port Variable Pressure sampling inlet, able to handle process pressures between 1000 mBar and 0.3 mBar
  • Samples from headspace above the product, measuring the bulk API in the dryer and avoiding problems with grab samples caused by lack of homogeneity.
  • Easy, simple calibration with either gases or liquids ensures accurate quantitative data
  • 21 CFR Part 11 compliant GasWorks software
Thermo Scientific Gas Analysis Mass Spectrometers

Thermo Scientific Gas Analysis Mass Spectrometers have been used successfully for over 30 years on bacterial and microbial processes. More recently, there has been increasing interest in mammalian cell culture because they offer the prospect of radical advances in vaccines, monoclonal antibodies and gene therapy. Although the requirements of mammalian cell fermentation processes provide challenges to the off-gas analyzer, our mass spectrometers have already proved invaluable in improving understanding and increasing yields of mammalian cell cultures.

In mammalian cell fermentations, the feed gas composition is a frequently changing mixture of several compounds. The feed gas concentration also ranges vary dramatically. The implementation of real-time, off-gas Mass Spectrometry in mammalian cell culture can help identify process deviations during bioreactor runs and evaluate batch to batch variation, within predefined specifications, for robust manufacturing.

Prima BT Bench Top Mass Spectrometer

Prima BT is a highly reliable, precise and flexible gas analyzer specifically designed for process development laboratories. Features include:

  • Scanning magnetic sector technology for fast, flexible, precise multi-component analysis. Concentrations of respiratory gases, inerts and volatiles can be measured in seconds with high levels of precision.
  • Configured with 15 sample and 6 calibration ports for fast, reliable monitoring of multiple fermenters and bioreactors using 16-port Rapid Multistream Sampler (RMS).
  • 21 CFR Part 11 compliant GasWorks Process MS Software.
Prima PRO Process Mass Spectrometer

Prima PRO is currently the world’s leading process mass spectrometer, designed to operate reliably in harsh production environments and backed up with an industry-best three year warranty. Features include:

  • Scanning magnetic sector technology for fast, flexible, precise multi-component analysis. Concentrations of respiratory gases, inerts and volatiles can be measured in seconds with high levels of precision.
  • 32- or 64-port Rapid Multistream Sampler (RMS) for fast, reliable monitoring of multiple fermenters and bioreactors.
  • Avoid compromising sterility with non-invasive sampling.
  • 21 CFR Part 11 compliant GasWorks Process MS Software.

Thermo Scientific GasWorks Process MS software provides the unique and powerful interface for the Prima PRO, Prima BT, Sentinel PRO and APIX δQ Mass Spectrometers. The software has been designed to ensure that the process analyzer is simple to configure, operate and maintain without any prior mass spectrometer experience.

The suite includes a wide range of functions and features. Whether the requirement is for a simple alarm indication in the event of a manufacturing process failure, or for complex data presentation for process understanding and control, Gasworks Software is well equipped to offer an effective solution.

  • Supports stand-alone analyzer operation.
  • Sets no limits to the number of sample streams or analytical methods.
  • Includes rigorous mathematical equations to deconvolute complex mixtures.
  • Multi-layered security with expiring passwords and audit trail.
  • Supports the integration of third-party analytical data.
